Wireline Systems Depth Panels

Standard Features (for premium line. sizes: 2U, 3U, & 9” x 6.5”)

• 3 sizes available for Premium Line:

  • Standard 2U rack mountable. Fits in 19” rack, 3.47” high, 7.3” deep.

  • Standard 3U, Fits in 19” rack or console cutout, 5.22” high, 4.6” deep.

  • Console, 9”w x 6.5”h x 5.6”d

  1. Internal activity “Tattletale” recording, up to 10 times per second. Save to external USB Stick Drive. (.csv format)

  2. Dual Depth Display (Depth & Depth+Offset).

  3. Field depth calibration (Per 1000 ft), depth correction (w/o losing ‘Zero’).

  4. Alarms: 3 Operator configurable (Audio/Visual) for depth, tension, tension spike, & speed.

     • Audible, 100DB @36”

     • Visual, Flashing Text

     • Relay Output

  5. 12VDC (Truck Battery) operation.

  6. Depth voice prompt. Audible annunciation: Depth, Approaching surface.

  7. Digital Depth and Speed readout (Feet/meters per minute/hour)

  8. Signature direction arrow.

  9. Digital Tension readout with configurable Tension Spike gauge (differential & absolute Tension, Lbs./Kgs.).

  10. Operator configurable English/Metric Depth, Tension & Speed units (In any combination).

  11. Output for logging system (Depth/Tension) (Warrior® System Compatible). Including Tension Output for easy Warrior® System Tension calibration.

  12. Slickline version available with Warrior®  compatible log files. (.4gdl format)

  13. Intuitive & elegant operator interface via 10" or 7” LED touchscreen (Wide viewing angle, Tiltable display).

      1. 2U & 3U Premium units allows the Tiltable Display to be remotely mounted anywhere in front of Hoistman, and can be adjusted to reduce glare from sun. 10” display (or compatible size)

Options

• (Optional) Network Communication and Control Package: Send depth/speed/tension info to remote computer or Smart Phone/Tablet

  • Pre-configured wireless router.

  • Windows Remote Master for view/control.

  • Windows Remote Slave for view only.

• (Optional) Advanced Calibration Package:

  • Easy wheel calibration, simply enter the correct depth reading and the system does the rest.

  • Canned or operator defined profiles for Line Stretch, Tension Coefficient, & Wheel Diameter Coefficient for 3/16, 7/32, 9/32, 5/16, 3/8 line sizes & Custom (for any line size).

• (Optional) Relays Package (2 normally open/normally closed relays).
